West Side Lumber Co. #12

Type: Class C Shay

Gauge: 36"

Date Created: 11APR2003 Updated: 05JAN2006

KUID: 86661:12

Download Now

UPDATED FOR TRS2006

Narrowgauge Class C Shay geared logging locomotive. This model represents builder's serial number 3302 operated on the West Side Lumber Co. railroad operations as the number 12 out of Tuolumne in the state of California from 1940 to 1961. Uses a heavy girder steel frame and cast steel bogey frames. It was built in the Lima shops in 04-21-1926 originally for the Swayne Lumber Co., Oroville California. This locomotive is on the Shay Survivor List and now operates on tourist excursions as the Georgetown Loop RR #12, Silver Plume Colorado.

This model was originally made for UTC but will work in TRS2004.

UPDATED!!! Now works with Trainz version TRS2006!!!

PROTOTYPE SPECIFICATIONS

Wheels:

12 at 32" dia.

Cylinders:

[#-Diam x Stroke]
3 - 11 x 12

Empty Weight:

113,500 lbs

Tractive Effort:

25,830 lbs

Gear Ratio:

2.529

Boiler Pressure:

200psi

Fuel Capacity:

1200 gals oil

Water Capacity:

2000 gals





West Side #12 Model Information


This locomotive was developed using GMax 1.2. It was my first locomotive modeling effort and took approximately five months to complete from start to finish. It was the first Class C Shay available for Trainz. This loco has a moderatly high poly count of 12,000 but performs well on most machines with modern graphics cards with 64M ram or higher. Since this is a non-LOD model, it is recommended that your Trainz performance settings for polycount be set to maximum level to avoid poly clipping.

The following individuals contributed greatly to the completion of this model and I am forever grateful for their assistance:

Todd Hohlenkamp - original driveline mesh and animation concepts

Peter-Pardoe Matthews - mesh modifications and animation assistance

Roger Crouch - mesh modifications and poly reduction

Gary Hoorn - Engine sounds

Mike Sutton - Texture samples and testing

Bob Pearson - Engine spec files and testing

Shane Perriman - Engineer and Fireman models, smoke effects code, testing

Dirk Mewes - Mesh sharing and headlight assembly

TrainzProRoutes Team - Testing and feedback



KUID Table
KUID
DESCRIPTION
86661:12
WSLC #12 locomotive body
86661:50030
fwd bogey truck
86661:50031
aft bogey truck
86661:50032
fwd line shaft
86661:50033
cylinder assembly and crankshaft
86661:50034
aft line shaft
86661:51012
enginespec note: this is a UTC model and does not incorporate TRS2004 steam effects. The engine can be driven in cabin mode but operates with a "diesel" style enginespec and control specification. The enginespec is set up to simulate the tractive effort and top speed of the prototype.
86661:53012
enginesound
86661:54012
hornsound
86661:55012
interior
86661:15112
WSLC #12 tender body
86661:50036
tender bogey truck
86661:50035
tender line shaft
